Ergonomic handheld form
Balanced dimensions support comfortable use during extended presentations.
Microphones
Model JI110H-C · wireless
Wireless Handheld Condenser Microphone
Wireless handheld microphone with color display, digital RF transmission, camera tracking support and long battery operation.
JI110H-C
01 / 02
TransducerCondenser
TransmissionDigital wireless RF
RF output15 mW
Bandwidth30 MHz
Battery2600 mAh
Overview
Handheld wireless clarity with at-a-glance status.
The Jistron JI110H-C is an ergonomic wireless handheld condenser microphone for meetings, presentations and professional events.
An approximately 1-inch HD color display shows battery, signal, microphone status, channel and ID. Digital RF transmission, automatic identification and camera tracking support integrate the microphone into compatible networked conference systems.
Engineering
Key features
HD color display
Battery, signal, microphone status, channel and ID are visible at a glance.
Digital RF
Digital wireless transmission provides stable integration with the compatible main unit.
Long battery life
A built-in 2600 mAh battery delivers up to 17 hours speaking and 50 hours standby.
Capsule options
Supports wide-frequency dynamic and optional large-diaphragm condenser capsule configurations.
Camera tracking
Automatic unit IDs support presenter tracking in compatible conference systems.
Interference resistance
The wireless platform is engineered for reliable professional operation.
Charging dock
A dedicated dock provides convenient storage and recharging.
Operational functions
Control designed into the unit.
BatterySignalMic StatusChannelID NumberCamera Tracking
Technical data
Specifications
Technical data for model JI110H-C.
Microphone & RF
- Product type
- Wireless handheld condenser microphone
- Transducer
- Condenser
- Transmission
- Digital wireless RF
- Frequency bandwidth
- 30 MHz
- Maximum deviation
- ±45 kHz
- RF output
- 15 mW
- Harmonic radiation
- < -65 dBm
Display & system
- Display
- Approximately 1-inch HD color display
- Displayed status
- Battery · signal · microphone status · channel · ID
- Camera tracking
- Supported
- Unit identification
- Automatic ID assignment
- System audio
- Network audio through the compatible main unit
Power & physical
- Battery
- Built-in 2600 mAh 18650 lithium battery
- Speaking time
- Up to 17 hours
- Standby time
- Up to 50 hours
- Charging
- Dedicated charging dock
- Dimensions
- Ø51 × 258 mm
- Weight
- 0.38 kg
Ordering information
- Model
- JI110H-C
- Description
- Wireless handheld condenser microphone
Product documentation
JI110H-C Datasheet
Complete RF, display, battery, system and physical specifications for the JI110H-C.
