Dual-bay charging
Charges two compatible wireless transmitters at the same time.
Microphones
Model JI130C · wireless
Network Charging Dock
Dual-bay network charging dock for bodypack and handheld transmitters with linked charging and software monitoring.
JI130C
01 / 02
Capacity2 transmitters
CompatibilityBodypack & handheld
Linked docksUp to 4
Network100 Mbps IP
Power5 V DC · 3.0 A
Overview
Networked dual-bay charging for wireless transmitters.
The Jistron JI130C charges two compatible bodypack or handheld transmitters while presenting clear LED status at each bay.
Up to four docks can be linked and powered from a single supply. A 100 Mbps network interface and manager software support charging oversight for organized wireless-system operations.
Engineering
Key features
Bodypack support
Compatible bodypack transmitters charge in approximately three hours.
Handheld support
Compatible handheld transmitters charge in approximately four hours.
Link up to four docks
Four linked docks can share one power supply for a consolidated installation.
Network management
A 100 Mbps IP connection supports compatible manager software.
LED status
Dedicated indicators show the charging state for quick visual confirmation.
Compact placement
A compact 200 × 95 mm footprint fits control rooms and equipment areas.
Complete accessories
Connection cable, AC adapter and AC power cord are included.
Operational functions
Control designed into the unit.
Dual-bayBodypackHandheldLink x4LED Status100 Mbps IP
Technical data
Specifications
Technical data for model JI130C.
Charging system
- Product type
- Network charging dock
- Charging positions
- 2
- Bodypack charge time
- Approximately 3 hours
- Handheld charge time
- Approximately 4 hours
- General charge time
- Approximately 4 hours
- Linked docks
- Up to 4; one power supply can power four linked docks
- Status indication
- LED
Network, power & physical
- Network interface
- 100 Mbps IP
- Software
- Compatible manager software
- Power input
- 5 V DC · 3.0 A
- Operating temperature
- 0-40 °C (32-104 °F)
- Dimensions
- 200 × 95 × 90 mm
- Weight
- 0.55 kg
- Included
- Connection cable · AC adapter · AC power cord
Ordering information
- Model
- JI130C
- Description
- Dual-bay network charging dock for bodypack and handheld transmitters
Product documentation
JI130C Datasheet
Complete compatibility, charging, network, electrical and physical specifications for the JI130C.
